1SB2485130402 Soundproof, insulating, damping, sealing devices
/ Foton 4189SLFKA-AEZA01

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: 1SB2485130402 Soundproof, insulating, damping, sealing devices / Foton 4189SLFKA-AEZA01
1SB2485130402
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Поз. Артикул Название детали Кол-во Цена
1SB2485130402 1SB2485130402 Soundproof, insulating, damping, sealing devices 1; -
1 Н4513020022А0 Heat insulator 12, high-top roof 1; -
2 Н4513020024А0 Heat insulator 14, high-top roof 1; -
3 Н4513020019А0 Heat insulator 9, high-top roof 1; -
4 Н4513020021АО Heat insulator 11, high-top roof 1; -
5 Н4513020023А0 Heat insulator 13, high-top roof 1; -
6 Н4513020020А0 Heat insulator 10, high-top roof 1; -
7 Н4513020017А0 Heat insulator 7, high-top roof 1; -
8 Н4513020018А0 Heat insulator 8, high-top roof 2; -
9 Н4513020016А0 Heat insulator 6, high-top roof 1; -
10 Н4513020014А0 Heat insulator 4, high-top roof 1; -
11 Н4513020011АО Heat insulator 1, high-top roof 1; -
12 Н451302001ЗАО Heat insulator 3, high-top roof 1; -
13 Н4513020012А0 Heat insulator 2, high-top roof 1; -
14 Н4513020015А0 Heat insulator 5, high-top roof 1; -
15 Н4513010011А0 Sound insulator 1, front wall 1; -
16 Н4513010012А0 Sound insulator 2, front wall 1; -
17 Н4513010013А0 Sound insulator 3, front wall 1; -
18 Н4513010014А0 Sound insulator 4, front wall 1; -
19 Н4513010015А0 Sound insulator 5, front wall 1; -
20 Н4513010017А0 Sound insulator 7, front wall 1; -
21 Н4513010016А0 Sound insulator 6, front wall 1; -
22 Н4513024102А0 Drum bag heat insulation pad 1; -
23 Н4513040016А0 Insulation mat button 43; -
24 Н4513010004А0 Sound insulator, floor 1; -
25 Н4513010003А0 Sound insulator, floor 1; -
26 Н4513040001АО Hole sticker 60, floor 8; -
27 Н4513040003А0 Hole sticker 25, floor 70; -
28 Н4513040002А0 Hole sticker 35, floor 16; -
29 Н4513040021АО Hole sticker 100, floor 2; -
30 Н4513040025А0 Block cover, panel, rear wall 4; -
31 Н4513040006А0 Block cover, panel, rear wall 2; -
32 Н4513040007АО Block cover, welded nut hole, rear wall 4; -
33 Н4513040008А0 Block cover, rear section, floor 8; -
34 H4513040009A0 Block cover, front panel 2; -
35 H4513040010A0 Double-layer rubber plug, rear wall 1; -
36 H4513040011A0 Block cover 1, side member, floor 2; -
37 H4513040012A0 Block cover 2, side member, floor 2; -
38 H4513040013A0 Block cover, side frame, floor 8; -
39 H4513014002A0 Acoustic board, wheel housing 1; -
40 H4513014001A0 Acoustic board, wheel housing 1; -
41 1K16951200804 Rubber plug 4; -
42 H4513024001A0 Heat insulator, wheel housing 1; -
43 H4513024003A0 Heat insulator, wheel housing 1; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
