1SB2485350411 Instrument panel
/ Foton 4189SLFKA-AEZA01

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: 1SB2485350411 Instrument panel / Foton 4189SLFKA-AEZA01
13
26
29
9
11
12
Поз. Артикул Название детали Кол-во Цена
23 Q2214816F31 Cross-recessed pan head self-tapping screw and big washer assembly 15; -
14 H4535010130A0 Instrument cover 1; -
15 Q2214216F31 Tapping screw 11; -
16 H4535010140A0 Panel assembly, driver side 1; -
17 H4535010150A0 Panel assembly, co-driver side 1; -
18 H4535010155A0 Apron panel, driver side 1; -
19 H4535010160A0 Apron panel, driver side 1; -
20 H4535010303A0 Apron panel, driver side 1; -
21 H4535010305A0 Apron panel, co-driver side 1; -
22 H4535010185A0 Maintenance lid assembly 1; -
13 H4535010322A0 Storage box 1; -
24 H4535010190A0 Retaining chute, maintenance lid 1; -
25 H4535010175A0 Retaining chute, apron panel 4; -
26 H4535010312A0 Storage box 1; -
27 1B24951200041 Гайка пластиковая 3; -
28 H4535010255A0 Subassembly 1; -
29 H4535010330A0 Footboard and bracket assembly, berth 1; -
30 Q2214222F31 Cross-recessed pan head self-tapping screw and big washer assembly 2; -
31 H4535010333A0 Bracket 1; -
10 H4535010250A0 Instrument panel module assembly 1; -
1 H4535030041A0 Attachment bracket, left end, instrument panel 1; -
2 H4535010120A0 Garnish, body, instrument panel 1; -
3 Q1460820 Болт с шестигранной головкой, пружинная шайба и плоская шайба 20; -
4 H4535010195A0 Angle plate assembly 1; -
5 H4535010196A0 Angle plate assembly 1; -
6 H4535010307A0 Mounting bracket, apron panel, co-driver side 1; -
7 Q32008 Гайка шестигранная с зубчатым буртиком 2; 240 ₽
8 H4535030042A0 Attachment bracket, right end, instrument panel 1; -
9 H4535010320A0 Panel assembly, storage box 1; -
1SB2485350411 1SB2485350411 Instrument panel 1; -
10.1 H4535010010A0 Body assembly, instrument panel 1; -
10.2 H4535010040A0 Panel assembly, co-driver side 1; -
10.3 H4535010050A0 Base assembly, dashboard 1; -
10.4 H4535030060A0 Tubular beam set assembly 1; -
10.5 H4535010030A0 Panel assembly, driver side 1; -
10.6 H4535010060A0 Control panel assembly 1; -
11 Q1860616F31 Hexagon flange bolt-oversize series 14; -
12 H4535010310A0 Panel assembly, storage box 1; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
