Gears composite member
/ HOWO Howo A7 8x4
1
2
3
4
5.1
5.2
5.3
5.4
6
7.1
7.2
7.3
7.4
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56.1
56.2
57
58
59
60
61
62
63
64
65
66
67
68
69
| Поз. | Артикул | Название детали | Цена | ||
|---|---|---|---|---|---|
| 1 | AZ2220100105 | Transmission housing | - | ||
| 2 | WG9003326020 | Roller bearing | 1 | - | |
| 3 | Q5280630 | Pin | 1 | - | |
| 4 | Q5280430 | Pin | 5 | - | |
| 5 | AZ2203100002 | Plant bracket assemby | 5 | - | |
| 5.1 | WG9003821255 | Hex screw | 1 | - | |
| 5.2 | WG2225100002 | Plant bracket assemby | 5 | - | |
| 5.3 | WG2229100001 | Torque sleeve | 1 | - | |
| 5.4 | AZ2225100001 | Output shaft | 5 | - | |
| 5.5 | AZ9007970271 | Glue | 1 | - | |
| 6 | WG2229100005 | Sun gear gasket | 1 | - | |
| 7 | AZ2203100003 | Sun roller and shealth assemby | 1 | - | |
| 7.1 | WG2210100002 | Spine sleeve | 1 | - | |
| 7.2 | Q43875 | Retainer | 1 | - | |
| 7.3 | WG2210100003 | Sleeve | 1 | - | |
| 7.4 | WG2210100001 | Sun gear | 1 | - | |
| 8 | WG2212100001 | Planet gear | 5 | - | |
| 9 | WG2229100007 | Block | 15 | - | |
| 10 | WG9003321118 | Roller | 120 | - | |
| 11 | WG2210100004 | Planet gear | 5 | - | |
| 12 | WG2229100006 | Shim | 1 | - | |
| 13 | WG2229100008 | Shim | 10 | - | |
| 14 | WG9003991056 | Retainer | 1 | - | |
| 15 | WG9003326322 | Roller bearing | 1 | - | |
| 16 | WG9003991125 | Retainer | 1 | - | |
| 17 | WG9003321820 | Roller bearing | 1 | - | |
| 18 | WG2210100005 | Annular gear | 1 | - | |
| 19 | WG2210100006 | Bracket | 1 | - | |
| 20 | WG2229100012 | Retainer | 1 | - | |
| 21 | Q15081240 | болт | 9 | - | |
| 22 | Q40112 | Шайба | 9 | - | |
| 23 | WG2229100002 | Torque sleeve | 9 | - | |
| 24 | WG2203100005 | Gear hub assemby | 1 | - | |
| 25 | WG2229100032 | Block sleeve | 1 | - | |
| 26 | WG2210100009 | Syn ring | 2 | - | |
| 27 | WG2210100007 | Syn tooth base | 1 | - | |
| 28 | WG2229020001 | Block | 9 | - | |
| 29 | WG2229020002 | Spring | 9 | - | |
| 30 | WG2229020003 | Spring cage | 9 | - | |
| 31 | WG9003991130 | Retainer | 1 | - | |
| 32 | WG2210100008 | Syn sleeve | 1 | - | |
| 33 | WG2229100042 | Shaft fork swing block | 2 | - | |
| 34 | WG2214100001 | Shaft fork | 1 | - | |
| 35 | WG2203100006 | Gear hub assemby | 1 | - | |
| 36 | WG2203100007 | Guide ring assemby | 1 | - | |
| 37 | WG9003990024 | Wave spring washer | 2 | - | |
| 38 | WG2229100043 | Shaft fork support pin | 2 | - | |
| 39 | WG2229100048 | Plate gasket | 1 | - | |
| 40 | WG2229100041 | End plate gasket | 1 | - | |
| 41 | WG2229100047 | Pto shaft cover | 1 | - | |
| 42 | Q15081216 | Hex bolt | 4 | - | |
| 43 | Q40312 | Пружинная шайба | 4 | - | |
| 44 | WG9003326218 | Roller bearing | 1 | - | |
| 45 | 22208100003 | Adjust shim | 1 | - | |
| 45.1 | WG2229100035 | Adjust shim | 1 | - | |
| 45.2 | WG2229100036 | Adjust shim | 1 | - | |
| 45.3 | WG2229100037 | Adjust shim | 1 | - | |
| 46 | WG2210100015 | Range worm | 1 | - | |
| 47 | WG9003072503 | O-ring | 2 | - | |
| 48 | WG9003071700 | O-ring | 1 | - | |
| 49 | WG2229100050 | Piston | 1 | - | |
| 50 | WG9003076900 | O-ring | 1 | - | |
| 51 | AZ9003870016 | Hex nut | 1 | - | |
| 52 | WG2229100049 | Paper gasket | 1 | - | |
| 53 | WG2222100009 | Cyclinder | 1 | - | |
| 54 | Q15OB1065 | Hex bolt | 4 | - | |
| 55 | Q40310 | Пружинная шайба | 4 | - | |
| 56 | AZ2203100008 | End plate assemby | 1 | - | |
| 56.1 | WG2222100001 | End plate assemby | 1 | - | |
| 56.2 | WG2203100009 | Connected assemby | 1 | - | |
| 57 | Q150B1055 | болт | 6 | - | |
| 58 | AZ9003070105 | Oil seal | 1 | - | |
| 59 | WG2210100018 | Output flange | 1 | - | |
| 60 | Q150B1020 | болт | 1 | - | |
| 61 | WG2229210019 | Spring | 1 | - | |
| 62 | WG2203100012 | Pin | 1 | - | |
| 63 | WG2229100056 | Pin | 1 | - | |
| 64 | WG2229100175 | Subplate | 1 | - | |
| 65 | Q15OB1025 | Hex bolt | 5 | - | |
| 66 | WG2229100052 | Subplate | 1 | - | |
| 67 | WG2229100054 | Press block | 5 | - | |
| 68 | WG2229100174 | Subplate | 1 | - | |
| 69 | WG2229100173 | Locking plate | 1 | - | |
| 70 | AZ9007990001 | Glue | 1 | - | |
| 71 | Q170B1055 | Hex holed bolt | 1 | - | |
| 72 | Q40310 | Пружинная шайба | 7 | - | |
| 73 | AZ9007970242 | Glue | 1 | - | |
| 74 | WG2229100072 | Press block | 1 | - | |
| 75 | WG2229100073 | Bolt | 1 | - | |
| 76 | Q150B0820 | болт | 1 | - | |
| 77 | AZ2229100075 | Cover | 1 | - | |
| 78 | Q40310 | Пружинная шайба | 1 | - | |
| 79 | AZ9007970271 | Glue | 1 | - | |
| 80 | WG2229100062 | Paper gasket | 1 | - | |
| 81 | WG2229100061 | Hange plate | 1 | - | |
| 82 | Q150B1050 | Hex bolt | 16 | - | |
| 83 | Q150B1060 | Hex bolt | 6 | - | |
| 84 | Q40310 | Пружинная шайба | 24 | - | |
| 85 | WG2229100011 | Fasten nut | 1 | - | |
| 86 | WG2229100071 | Plug | 1 | - | |
| 87 | WG2229100074 | Locking plate | 1 | - | |
| 88 | WG2214100002 | Shaft fork | 1 | - | |
| 89 | WG9003070800 | O-ring | 1 | - | |
| 90 | WG9003801187 | Bolt | 1 | - | |
| 91 | WG9003070800 | O-ring | 1 | - | |
| 92 | WG9003801058 | Hex bolt | 2 | - | |
| 93 | WG9003073150 | O-ring | 1 | - | |
| 94 | WG9003345138 | Roller pin | 1 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
