Chassis Frame Assy
/ HOWO ZZ3327N3647C-N2WA
1
3
3
5
9
16
21
37
37
38
38
44
50
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | AZ9725513615 | Chassis frame assy | 1; | - | |
| 2 | AZ9725513616 | Left longeron | 1; | - | |
| 3 | AZ9725513617 | Right longeron | 1; | - | |
| 4 | AZ9725513618 | Left auxiliary beam | 1; | - | |
| 5 | AZ9725513619 | Right auxiliary beam | 1; | - | |
| 6 | Q4501236 | Rivet | 11; | - | |
| 7 | Q150B1635 | Screw | 4; | - | |
| 8 | Q33216 | Гайка | 4; | - | |
| 9 | AZ9725510100 | Cross member | 1; | - | |
| 10 | AZ9725510071 | Cross member | 1; | - | |
| 11 | AZ9725510101 | Left upper plate | 1; | - | |
| 12 | AZ9725510102 | Right upper plate | 1; | - | |
| 13 | AZ9725513858 | Left lower plate | 1; | - | |
| 14 | AZ9725513859 | Right lower plate | 1; | - | |
| 15 | Q4501228 | Rivet | 16; | - | |
| 16 | Q4501242 | Rivet | 10; | - | |
| 17 | Q150B1240TF2 | Screw | 2; | - | |
| 18 | Q33212T13F2 | Nut | 2; | - | |
| 19 | Q150B1645TF2 | Screw | 2; | - | |
| 20 | Q33216T13F2 | Nut | 2; | - | |
| 21 | AZ9731513265 | Cross member | 1; | - | |
| 22 | AZ9632510050 | Cross member | 2; | - | |
| 23 | AZ9731513272 | Upper plate | 2; | - | |
| 24 | AZ9731513273 | Lower plate | 2; | - | |
| 25 | Q4501230 | Rivet | 36; | - | |
| 26 | Q150B1245TF2 | Screw | 4; | - | |
| 27 | Q33212T13F2 | Nut | 4; | - | |
| 28 | Q4501250 | Rivet | 8; | - | |
| 29 | Q4501242 | Rivet | 12; | - | |
| 30 | AZ9731513859 | Front support plate | 2; | - | |
| 31 | Q4501244 | Rivet | 8; | - | |
| 32 | AZ9625510476 | Rear support plate | 2; | - | |
| 33 | Q4501244 | Rivet | 4; | - | |
| 34 | AZ9625510290 | Cross member | 1; | - | |
| 35 | AZ9625510044 | Cross member | 2; | - | |
| 36 | AZ9625510291 | Left plate | 1; | - | |
| 37 | AZ9625510292 | Right plate | 1; | - | |
| 38 | Q4501236 | Rivet | 40; | - | |
| 39 | Q4501244 | Rivet | 2; | - | |
| 40 | Q4501250 | Rivet | 24; | - | |
| 41 | AZ9625510043 | Plate | 2; | - | |
| 42 | Q4501252 | Rivet | 30; | - | |
| 43 | Q4501244 | Rivet | 12; | - | |
| 44 | AZ9731513280 | Cross member assy-rear | 1; | - | |
| 45 | AZ9731512021 | Cross member-rear | 1; | - | |
| 46 | AZ9731513277 | Left upper plate | 2; | - | |
| 47 | AZ9731513278 | Right upper plate | 2; | - | |
| 48 | AZ9731512024 | Plate | 1; | - | |
| 49 | Q4501232 | Rivet | 24; | - | |
| 50 | Q150B1645TF2 | Screw | 22; | - | |
| 51 | Q33216T13F2 | Nut | 22; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
