Cylinder block
/ HOWO ZZ3327N3647C-N2WA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
21
21
21
22
23
24
25
26
27
28
28
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
56
57
58
59
60
61
62
63
64
65
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 190003871252 | Nut | 5; | - | |
| 2 | 190003932023 | Spring washer | 5; | - | |
| 3 | 190003813429 | Stud | 5; | - | |
| 4 | 190003802576 | Screw | 1; | - | |
| 5 | 190003932024 | Spring washer | 1; | - | |
| 6 | VG2600010830 | Compressor gear cover | 1; | - | |
| 7 | VG14010040 | прокладка | 1; | - | |
| 8 | 190003871252 | Nut | 6; | - | |
| 9 | 190003813429 | Stud | 4; | - | |
| 10 | 190003932023 | Spring washer | 6; | - | |
| 11 | 190003813467 | Stud | 2; | - | |
| 12 | VG1095010070 | Oil fueling pipe | 1; | - | |
| 13 | 190003802321 | Screw | 4; | - | |
| 14 | 190003931082 | Spring washer | 4; | - | |
| 15 | VG14010086 | прокладка патрубка | 1; | - | |
| 16 | 190003901507 | Cylinder pin | 4; | - | |
| 17 | Q1201245F3 | Stud | 2; | - | |
| 18 | 190003813628 | Шпилька | 6; | - | |
| 19 | 190003888453 | Nut | 8; | - | |
| 20 | 190003900085 | Spring cylinder pin | 4; | - | |
| 21 | 190003931122 | Spring washer | 010; | - | |
| 22 | 190003802561 | Screw | 6; | - | |
| 23 | 190003800571 | Screw | 1; | - | |
| 24 | 190003802523 | Screw | 3; | - | |
| 25 | VG14010070 | прокладка крышки шестерни компрессора | 1; | - | |
| 26 | VG1500010008A | покрышка | 1; | - | |
| 27 | 190003813429 | Stud | 5; | - | |
| 28 | 190003932023 | Spring washer | 6; | - | |
| 29 | 190003871252 | Nut | 6; | - | |
| 30 | 190003932025 | Spring washer | 2; | - | |
| 31 | 190003862524 | Screw | 2; | - | |
| 32 | 190003813443 | Stud | 1; | - | |
| 33 | VG2600010934 | шпилька | 1; | - | |
| 34 | VG1047010038 | Oil sealing | 1; | - | |
| 35 | VG2600010928 | шпилька | 1; | - | |
| 36 | 190003901604 | Cylinder pin | 2; | - | |
| 37 | VG1096010060 | Oil separator | 1; | - | |
| 38 | Q150B0616 | болт | 1; | - | |
| 39 | 190003931082 | Spring washer | 1; | - | |
| 40 | Q734B2650265 | O-ring | 1; | - | |
| 41 | 190003901604 | Cylinder pin | 6; | - | |
| 42 | VG1540010006 | покрышка цилиндра | 6; | - | |
| 43 | 190003909603 | Spring cylinder pin | 6; | - | |
| 44 | VG1560019090 | агрегаты форсунки | 6; | - | |
| 45 | VG9003080005 | Sealing washer | 6; | - | |
| 46 | 190003962621 | Hollow bolt | 6; | - | |
| 47 | VG2600010735 | составная подкладка | 1; | - | |
| 48 | VG1460070011 | Болт | 1; | - | |
| 49 | VG1047010050 | Oil sealing | 1; | - | |
| 50 | 190003802511 | Screw | 2; | - | |
| 51 | VG1800210011 | покрышка | 1; | - | |
| 52 | VG1500010600 | верхние агрегаты | 1; | - | |
| 53 | VG2600010705 | низкие агрегаты | 1; | - | |
| 54 | VG1460010011 | Pipe | 1; | - | |
| 55 | VG1540010015A | Gasket | 1; | - | |
| 56 | 190003932023 | Spring washer | 014; | - | |
| 57 | Q150B0875 | Screw | 6; | - | |
| 58 | VG1540010014A | Cover | 1; | - | |
| 59 | 190003962020 | Plug | 1; | - | |
| 60 | VG9003080005 | Sealing washer | 1; | - | |
| 61 | 190003802437 | Screw | 6; | - | |
| 62 | VG1400010032 | манжета | 2; | - | |
| 63 | VG1500010125 | Стопорная шайба | 2; | - | |
| 64 | VG1540010022 | нижняя черепица | 7; | - | |
| 65 | VG1540010021 | верхняя черепица | 7; | - | |
| 66 | VG1500019067 | Clip | 1; | - | |
| 68 | 190003932023 | Spring washer | 2; | - | |
| 69 | Q150B0816 | болт | 1; | - | |
| 70 | VG61000010134 | манжета | 1; | - | |
| 71 | 190011260039 | Screw | 6; | - | |
| 72 | VG9003080001 | Washer | 6; | - | |
| 73 | 190003909626 | Spring cylinder pin | 6; | - | |
| 74 | VG407010046 | Washer | 1; | - | |
| 75 | 190003989336 | Хомут | 2; | - | |
| 76 | 190003800465 | Screw | 2; | - | |
| 77 | 190003930261 | Washer | 1; | - | |
| 78 | 190013050011 | Screw | 1; | - | |
| 79 | VG188250083 | Стопорное кольцо | 1; | - | |
| 80 | 190003930271 | Washer | 2; | - | |
| 81 | 190003962051 | Plug | 1; | - | |
| 82 | VG1500010005 | Seat | 2; | - | |
| 84 | 190003931122 | Spring washer | 012; | - | |
| 85 | VG29135 | Seal | 1; | - | |
| 86 | 190003802419 | Screw | 2; | - | |
| 87 | 190003932023 | Spring washer | 2; | - | |
| 88 | Q617B18 | Plug | 1; | - | |
| 89 | VG9003080007 | Gasket | 1; | - | |
| 90 | 190003989301 | Хомут | 1; | - | |
| 91 | VG12G00040038 | пластмассорезиновая трубка | 1; | - | |
| 92 | VG1092010101 | Nameplate | 1; | - | |
| 93 | VG29115 | Plugging cover | 1; | - | |
| 94 | VG2600010447 | Clip | 1; | - | |
| 95 | VG2600010446 | Hose for oil dipsticle | 1; | - | |
| 96 | VG2600010791 | Rivet | 4; | - | |
| 97 | VG288730061 | манжета | 1; | - | |
| 98 | VG1500010174 | резиновая трубка | 1; | - | |
| 99 | VG1095010033 | Hose | 1; | - | |
| 100 | 90003989301 | вязка | 2; | - | |
| 101 | VG609E110049 | окрепляющяя доска | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
