Front axle assembly
/ HOWO ZZ4257N3247N1B_A7_D12_380
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | AZ9900410083 | Front axle | 1; | - | |
| 2 | AZ9100411005 | Limit screw | 2; | - | |
| 3 | Q40314 | Пружинная шайба | 2; | - | |
| 4 | Q340B14T13F2 | 1 shape hex nut | 2; | - | |
| 5 | WG9100411035 | Shealth | 4; | - | |
| 6 | AZ9100413045 | Pin | 2; | - | |
| 7 | AZ9100413035 | Retainer | 2; | - | |
| 8 | AZ9003963004 | Grease assemby | 2; | - | |
| 9 | Q43070 | Retainer | 2; | - | |
| 10 | AZ9100413070 | Cover | 2; | - | |
| 11 | AZ9100413011 | Washer | 1; | - | |
| 11 | AZ9100413024 | Washer | 1; | - | |
| 12 | WG9700411049 | Thrusting bearing | 2; | - | |
| 13 | AZ9100411007 | Cover | 2; | - | |
| 14 | Q43055 | Retainer | 2; | - | |
| 15 | WG9100413052 | Protect housing | 1; | - | |
| 16 | Q150B1025 | болт | 8; | - | |
| 17 | Q361B24T13F2 | 2 type hex nut | 4; | - | |
| 18 | AZ9719413003 | Rotate level arm | 1; | - | |
| 19 | AZ9100413008 | Hex bolt | 4; | - | |
| 20 | WG9100413004 | Connect plate | 2; | - | |
| 21 | Q151B2045TF2 | болт | 4; | - | |
| 22 | WG9112410019 | Кольцевая шестерня для АВS | 2; | - | |
| 23 | WG9003074387 | Shaft seal ring | 2; | - | |
| 24 | WG9100032314 | Roller bearing | 2; | - | |
| 25 | WG9100032311 | Roller bearing | 2; | - | |
| 25.9 | AZ9100413060 | Front wheel assemby | 2; | - | |
| 26 | WG9100410212 | Bolt | 20; | - | |
| 27 | AZ9100413065 | Front wheel hub | 2; | - | |
| 28 | WG9003884160 | Колесная гайка | 20; | - | |
| 29 | WG9100410062 | Shim | 2; | - | |
| 30 | Q5006370 | Шпилька | 2; | - | |
| 31 | WG9100413068 | End plate | 2; | - | |
| 32 | Q150B0816 | болт | 20; | - | |
| 33 | Q40308 | Пружинная шайба | 20; | 10 ₽ - 60 ₽ | |
| 34 | AZ9100411140 | контрящая гайка поворотного кулака | 2; | - | |
| 35 | Q151B1690TF2 | Hex bolt | 20; | - | |
| 36 | AZ9719411011 | Knuckle arm | 1; | - | |
| 37 | Q151B1850TF2 | Hex bolt | 2; | - | |
| 38 | AZ9100413062 | Rotate joint | 1; | - | |
| 39 | AZ9100413063 | Rotate joint | 1; | - | |
| 40 | Q351B14T15 | низкая гайка | 2; | - | |
| 41 | WG880 410059 | Adjusting screw | 2; | - | |
| 42 | WG2297Y4835 | Sign | 1; | - | |
| 43 | WG9100413053 | Protect housing | 1; | - | |
| 44 | AZ9719413004 | Rotate level arm | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
