Transmission equipment
/ JAC Motors HFC 1020K-D126
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 2201000D4 | rear axle transmission shaft | 1; | - | |
| 2 | 2201021N57 | universal joint glide fork | 1; | - | |
| 3 | 2201022N57 | blocking | 1; | - | |
| 4 | 2201023N57 | oil seal | 1; | - | |
| 5 | 2201024N57 | dustproof cover | 1; | - | |
| 6 | 2201031N57 | flange yoke | 6; | - | |
| 7 | 2201041N57 | crossing axis | 6; | - | |
| 8 | 2201042N57 | slide grease nib | 6; | - | |
| 9 | 2201050N57 | needle bearing | 24; | - | |
| 10 | 2201061N57 | universal joint bearing retainer ring | 1; | - | |
| 11 | 2201062N57 | universal joint bearing retainer ring | 1; | - | |
| 12 | 2201063N57 | universal joint bearing retainer ring | 1; | - | |
| 13 | Q700B01 | lubricate nib | 2; | - | |
| 14 | 2201072Z8 | rear axle transmission shaft bolt | 4; | - | |
| 15 | Q341B10 | Nut | 8; | - | |
| 16 | Q40310 | spring washer | 8; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
