3506D120 Brake pipe system
/ JAC Motors HFC 1020K-D134
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 3506100E0 | oil storage boat | 1; | - | |
| 2 | 3506261E0 | master pump oil inlet hose | 2; | - | |
| 3 | 3510010D306 | vacuum booster with brake main jar unit | 1; | - | |
| 4 | 3506110D120 | brake master pump front brake pipe unit | 1; | - | |
| 5 | 3506120D120 | brake master pump rear brake pipe unit | 1; | - | |
| 6 | 3504020D2 | clutch master pedal and bracket noumenon unit | 1; | - | |
| 7 | 3506156E0 | vacuum soft hose | 1; | - | |
| 8 | 3506180D120 | vacuum soft hose connector unit | 1; | - | |
| 9 | 3506150D120 | seal board unit | 1; | - | |
| 10 | 3506160D120 | brake hose bracket unit | 1; | - | |
| 11 | 3506219E0 | clip | 1; | - | |
| 12 | 3506017D120 | vacuum soft hose | 1; | - | |
| 13 | 019.8-7.6R | clip ring | 10; | - | |
| 14 | 3506060D120 | front brake soft hose unit | 2; | - | |
| 15 | 3506010E0 | five-way bracket unit | 1; | - | |
| 16 | 3506120Z1 | diffluence tie-in unit | 1; | - | |
| 17 | 3506012D120 | front vacuum pipe | 1; | - | |
| 18 | 3506020D120 | right front brake pipe unit | 1; | - | |
| 19 | 3506010D120 | left front brake pipe unit | 1; | - | |
| 20 | 3506018B6 | front brake soft hose bracket | 2; | - | |
| 21 | 3506140D4 | front brake pipe unit | 2; | - | |
| 22 | 3506016D120 | vacuum soft hose | 1; | - | |
| 23 | 3524014D120 | vacuum hose | 1; | - | |
| 24 | 3506151E0 | three-way | 1; | - | |
| 25 | 3506015D120 | vacuum soft hose | 1; | - | |
| 26 | 3506040D120 | rear brake pipe unit | 1; | - | |
| 27 | 3506028Z1 | two-way | 1; | - | |
| 28 | 3524013D120 | rear vacuum pipe | 1; | - | |
| 29 | 3506200D120 | vacuum pipe unit | 1; | - | |
| 30 | 3524014D120 | vacuum hose | 1; | - | |
| 31 | 3506050D120 | rear brake pipe unit | 1; | - | |
| 32 | 3506016Z1 | rear brake oil pipe bracket | 1; | - | |
| 33 | 3506140Z1 | front brake pipe unit | 1; | - | |
| 34 | 3506219E0 | clip | 1; | - | |
| 35 | 3506080D120 | rear axle left brake pipe unit | 1; | - | |
| 36 | 3506014Z1 | three-way | 1; | - | |
| 37 | 3506090D120 | rear axle right brake pipe unit | 1; | - |
