M3400-1111000 iNJECTiON PUMP
/ Shaanxi MAN-F2000 (SX3254JS384)
1
2
3
4
5
5
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
40
41
42
43
44
| Поз. | Артикул | Название детали | 44 | 46 | 50 | 56 | 58 | Цена | |
|---|---|---|---|---|---|---|---|---|---|
| 1 | M3400-1111716 | Locking screw | 1 | 1 | 1 | 1 | 1 | - | |
| 2 | Q40314 | Шайба пружинная | 1 | 1 | 1 | 1 | 1 | - | |
| 3 | M3400-1111711 | Locking block | 1 | 1 | 1 | 1 | 1 | - | |
| 4 | M3400-1111715 | Nut | 1 | 1 | 1 | 1 | 1 | - | |
| 5 | M3400-1111713 | Screw | 6 | 6 | 6 | 6 | 6 | - | |
| 6 | M3400-1111720 | Clamp | 2 | 2 | 2 | 2 | 2 | - | |
| 7 | M3400-1111714 | Screw | 2 | 2 | 2 | 2 | 2 | - | |
| 8 | M3400-1111712 | Universal joint | 1 | 1 | 1 | 1 | 1 | - | |
| 9 | M3400-1111705A | Connection plate | 1 | 1 | 1 | 1 | 1 | - | |
| 10 | M3400-1111100 | Injection pump element | 1 | 1 | 1 | 1 | 1 | - | |
| 11 | Q5211222 | Штифт | 2 | 2 | 2 | 2 | 2 | - | |
| 12 | M3000-1111205 | Carrier | 1 | 1 | 1 | 1 | 1 | - | |
| 13 | E0200-1111035C | Pipe joint | 1 | 1 | 1 | 1 | 1 | - | |
| 14 | M3400-1111350 | Oil line | 1 | 1 | 1 | 1 | 1 | - | |
| 15 | M12x45 | Hex.screw | 4 | 4 | 4 | 4 | 4 | - | |
| 16 | JB/T982-14 | Combine seal gasket | 1 | 1 | 1 | 1 | 1 | - | |
| 17 | 150-1111071 | Трубное соединение | 1 | 1 | 1 | 1 | 1 | - | |
| 18 | Q40110 | Шайба | 2 | 2 | 2 | 2 | 2 | - | |
| 19 | Q40310 | Шайба | 2 | 2 | 2 | 2 | 2 | - | |
| 20 | Q150B1015 | Screw | 2 | 2 | 2 | 2 | 2 | - | |
| 21 | M3400-1111360 | Oil line | 1 | 1 | 1 | 1 | 1 | - | |
| 22 | M3400-1111014 | Bracket | 1 | 1 | 1 | 1 | 1 | - | |
| 23 | JB/T6013-1010 | Hinge screw | 1 | 1 | 1 | 1 | 1 | - | |
| 24 | JB/T6013-10 | Washer | 2 | 2 | 2 | 2 | 2 | - | |
| 25 | E0200-1111070 | Turbochager pipe | 1 | 1 | 1 | 1 | 1 | - | |
| 26 | Q5510636 | Штифт 6х36 | 1 | 1 | 1 | 1 | 1 | - | |
| 27 | Q39135 | Гайка М35х1,5 | 1 | 1 | 1 | 1 | 1 | - | |
| 28 | Q40835 | Стопорное кольцо | 1 | 1 | 1 | 1 | 1 | - | |
| 29 | GB/T9877.1-FB45628F | Seal | 1 | 1 | 1 | 1 | 1 | - | |
| 30 | JB/T6013-10 | Washer | 1 | 1 | 1 | 1 | 1 | - | |
| 31 | Q6107B10 | Plug | 1 | 1 | 1 | 1 | 1 | - | |
| 32 | M3400-1111701 | Bearing seat | 1 | 1 | 1 | 1 | 1 | - | |
| 33 | GB3452.1-80002650 | O-ring | 1 | 1 | 1 | 1 | 1 | - | |
| 34 | GB3452.1-11801800 | O-ring | 3 | 3 | 3 | 3 | 3 | - | |
| 35 | Q1841025TF2 | Hex.screw | 3 | 3 | 3 | 3 | 3 | - | |
| 36 | M3400-1111704 | Spacer sleeve | 1 | 1 | 1 | 1 | 1 | - | |
| 37 | Q43072 | Пружинное стопорное кольцо 72 | 1 | 1 | 1 | 1 | 1 | - | |
| 38 | Q1841080TF2 | Hex.screw | 4 | 4 | 4 | 4 | 4 | - | |
| 39 | M3400-1111703 | Spacer sleeve | 1 | 1 | 1 | 1 | 1 | - | |
| 40 | GB/T276-6207-2RS | Ball bearing | 2 | 2 | 2 | 2 | 2 | - | |
| 41 | M3400-1111702 | Propeller shaft | 1 | 1 | 1 | 1 | 1 | - | |
| 42 | M3400-1111003 | injection pump gear | 1 | 1 | 1 | 1 | 1 | - | |
| 43 | A30-1111129 | Driving shaft pin | 1 | 1 | 1 | 1 | 1 | - | |
| 44 | Q1841025TF2 | Hex.screw | 4 | 4 | 4 | 4 | 4 | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
