Жгут проводов рамы;Frame wiring harness
/ Shaanxi Shacman SX1255GP4
1
2
3
4
5
6
7
8
9
10
11
12
13
13
13
14
15
16
16
17
18
19
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| BZ40107083 | BZ40107083 | Frame wiring harness | 1; | - | |
| 1 | Connect to fuel tank | Connect to fuel tank | ; | - | |
| 2 | Connect to injection pump | Connect to injection pump | ; | - | |
| 3 | Connect to air solenoid valve | Connect to air solenoid valve | ; | - | |
| 4 | Connect to fuel tank level and temperature sensor | Connect to fuel tank level and temperature sensor | ; | - | |
| 5 | Connect to fuel water sensor | Connect to fuel water sensor | ; | - | |
| 6 | Connect to water cut-off solenoid valve | Connect to water cut-off solenoid valve | ; | - | |
| 7 | Connect to electronic odometer sensor | Connect to electronic odometer sensor | ; | - | |
| 8 | Connect to preheat relay | Connect to preheat relay | ; | - | |
| 9 | Connect to engine | Connect to engine | ; | - | |
| 10 | Connect to preheat plug | Connect to preheat plug | ; | - | |
| 11 | Connect to compressor | Connect to compressor | ; | - | |
| 12 | Connect to front panel wiring harness | Connect to front panel wiring harness | ; | - | |
| 13 | Connect to body wiring harness | Connect to body wiring harness | ; | - | |
| 14 | Connect to bumper wiring harness | Connect to bumper wiring harness | ; | - | |
| 15 | Grounding | Grounding | ; | - | |
| 16 | Connect to engine wiring harness | Connect to engine wiring harness | ; | - | |
| 17 | Connect to ambient temperature sensor | Connect to ambient temperature sensor | ; | - | |
| 18 | Connect to electric horn | Connect to electric horn | ; | - | |
| 19 | Connect to low water level alarm | Connect to low water level alarm | ; | - | |
| 20 | Connect to generator | Connect to generator | ; | - | |
| 21 | Connect to starter | Connect to starter | ; | - | |
| 22 | Connect to neutral | Connect to neutral | ; | - | |
| 23 | Connect to reverse gear | Connect to reverse gear | ; | - | |
| 24 | Connect to single-link combination solenoid valve | Connect to single-link combination solenoid valve | ; | - | |
| 25 | Connect to main power switch | Connect to main power switch | ; | - | |
| 26 | Connect to air pressure sensor 1 | Connect to air pressure sensor 1 | ; | - | |
| 27 | Connect to dryer | Connect to dryer | ; | - | |
| 28 | Connect to catalytic inlet temperature sensor | Connect to catalytic inlet temperature sensor | ; | - | |
| 29 | Connect to NOx sensor | Connect to nox sensor | ; | - | |
| 30 | Connect to 120 ohm resistor | Connect to 120 ohm resistor | ; | - | |
| 31 | Connect to air pressure sensor 2 | Connect to air pressure sensor 2 | ; | - | |
| 32 | Connect to three-color rear taillight | Connect to three-color rear taillight | ; | - | |
| 33 | Connect to rectangular rear marker light | Connect to rectangular rear marker light | ; | - | |
| 34 | Connect to side marker light harness | Connect to side marker light harness | ; | - | |
| 35 | Connect to ground | Connect to ground | ; | - | |
| 36 | Connect to reverse buzzer | Connect to reverse buzzer | ; | - | |
| 37 | Connect to three-color rear taillight | Connect to three-color rear taillight | ; | - | |
| 38 | Connect to rectangular rear marker light | Connect to rectangular rear marker light | ; | - | |
| 39 | Connect to side marker light harness | Connect to side marker light harness | ; | - |
