THE INTERIOR TRIM ASSEMBLY
/ Shaanxi Shacman SX13164N456

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: THE INTERIOR TRIM ASSEMBLY / Shaanxi Shacman SX13164N456
1
2
3
4
4
4
4
4
4
4
4
5
5
6
7
7
8
8
9
10
10
11
12
12
13
13
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Поз. Артикул Название детали Кол-во Цена
1 DZ14251610021 Behind ceiling 1; -
2 06.13129.0024 Self tapping screw 8; -
3 DZ14251610011 Front the lining 1; -
4 DZ13241610246 Buckle 29; -
5 Q2300620 Pan-head screw 2; -
6 DZ14251610012 Middle screen rail 1; -
7 DZ14251610014 Rail end cap 2; -
8 Q2204219 Right top lining 2; -
9 Q2714219 Cross groove pan head self-tapping screw 2; -
10 DZ14251610023 Bracket cover 16; -
11 DZ13241571413 Guide smooth bead 4; -
12 DZ14251610024 3m fastener 4; -
13 Q33006 Nut 1; -
14 DZ14251610176 Rear right stents 1; -
15 DZ14251610022 Light mounting bracket 1; -
16 DZ14251610175 Rear left stents 8; -
17 Q40204 Large washer 8; -
18 Q340B04 1 type hexagon nut 1; -
19 DZ14251610026 Rear curtain rail 9; -
20 DZ13241571424 Grab handle assembly 2; -
21 DZ13241571422 Plastic buckle 18; -
22 DZ13241571423 Rail end cap 4; -
23 Q42163 Flat gasket 4; -
24 Q271631 Self tapping screw 1; -
25 DZ14251610151 Skylight decorative cover 6; -
26 DZ14251610346 Retractor fixed support frame reed nut 5; -
27 DZ14251610112 Plastic buckle ; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
