STEYR 6.5 TONS STEERING SHAFT
/ Shaanxi Shacman SX3316DT366
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
19
20
21
21
22
22
23
24
25
25
25
26
27
28
29
30
31
32
33
34
35
35
35
35
36
37
38
39
40
41
42
43
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 81.96002.0368 | 81.96002.0368 | Blocking | 2; | - | |
| 1 | Q150B0816 | Болт | 16; | - | |
| 2 | Q40308 | Шайба пружинная | 16; | 10 ₽ - 60 ₽ | |
| 3 | 188000410043 | Cap | 2; | - | |
| 4 | Q5006375 | Шплинт | 2; | - | |
| 5 | 1160-3001141 | Hex bolt | 2; | - | |
| 6 | DZ91009410028 | Washer | 2; | - | |
| 7 | 32310 | Row-steep roller bearing | 2; | 1 070 ₽ | |
| 8 | 190003884160 | Гайка | 20; | - | |
| 9 | 199112410009 | Front Whee hub | 2; | - | |
| 10 | 199000410104 | Wheel bolt | 20; | - | |
| 11 | 199112410019 | ABS gear ring | 2; | - | |
| 12 | 32314 | Подшипник | 2; | - | |
| 13 | 190003070044 | Packing ring | 2; | - | |
| 14 | 199000410114 | Bushing | 2; | - | |
| 15 | 129500420033 | O style packing ring | 2; | - | |
| 16 | 199112410055 | Steering knuckle | 1; | - | |
| 16 | 199112410056 | Steering knuckle | 1; | - | |
| 17 | 190003901506 | Pin | 2; | - | |
| 18 | DZ91009410026 | Washer | ; | - | |
| 18 | DZ91009410025 | Washer | ; | - | |
| 18 | DZ91009410024 | Washer | ; | - | |
| 18 | DZ91009410023 | Washer | ; | - | |
| 18 | DZ91009410022 | Washer | ; | - | |
| 18 | DZ91009410021 | Washer | ; | - | |
| 18 | DZ91009410020 | Washer | ; | - | |
| 18 | DZ91009410019 | Washer | ; | - | |
| 18 | 188000410096 | Washer | ; | - | |
| 18 | 188000410104 | Washer | ; | - | |
| 18 | 188000410097 | Washer | ; | - | |
| 18 | 188000410105 | Washer | ; | - | |
| 18 | 188000410106 | Washer | ; | - | |
| 18 | 188000410108 | Washer | ; | - | |
| 18 | 188000410094 | Washer | ; | - | |
| 18 | 188000410107 | Washer | ; | - | |
| 18 | 188000410095 | Washer | ; | - | |
| 19 | 188000410052 | O style packing ring | 2; | - | |
| 20 | 188000410035 | Bush | 2; | - | |
| 21 | AZ9100410033 | Кронштейн (левый) | 1; | - | |
| 21 | AZ9100410037 | Кронштейн | 1; | - | |
| 22 | DZ91009410005 | Bush | 4; | - | |
| 23 | DZ9003800004 | Bolt | 8; | - | |
| 24 | 190003963114 | Taper thread grease nipple | 2; | - | |
| 25 | 199000410001 | Steering knuckle arm | 1; | - | |
| 25 | 199014410001 | Steering knuckle arm | 1; | - | |
| 25 | 199000410045 | Steering knuckle arm | 1; | - | |
| 26 | Q151B1850TF2 | Hex bolt | 2; | - | |
| 27 | DZ9100580215 | Втулка датчика | 2; | - | |
| 28 | DZ9100580214 | Датчик АВS | 2; | - | |
| 29 | Q151C1220 | Болт | 4; | - | |
| 30 | 188000410059 | Hex bolt | 2; | - | |
| 31 | Q351B14T15 | Гайка | 2; | - | |
| 32 | 190003963112 | Масленка | 2; | - | |
| 33 | Q5005050 | Шплинт | 4; | - | |
| 34 | 190003872377 | Hex nut | 4; | - | |
| 35 | 199018410004 | Steering cross rod arm | 1; | - | |
| 35 | 199018410005 | Steering cross rod arm | 1; | - | |
| 35 | 188000410040 | Steering cross rod arm | 1; | - | |
| 35 | 188000410041 | Steering cross rod arm | 1; | - | |
| 36 | 188000410038 | Break hoof pin | 4; | - | |
| 37 | 188000410031 | Steering knuckle pin | 2; | - | |
| 38 | 188000410054 | Front axle | 1; | - | |
| 39 | 188000410049 | Thrust roller bearing | 2; | - | |
| 40 | 188000410029 | Bush | 2; | - | |
| 41 | 188000410100 | Cover | 2; | - | |
| 42 | Q43056 | Кольцо стопорное | 2; | - | |
| 43 | 199100430018 | Steering cross rod | 1; | - | |
| 43 | 199018430006 | Рулевая тяга | 1; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
