MAN9.5T STEERING SHAFT
/ Shaanxi Shacman SX3316DT426C
1
2
3
4
5
5
6
7
8
9
10
11
12
13
13
14
14
15
16
17
17
17
17
18
18
19
20
21
21
22
23
24
25
26
26
26
26
26
26
26
26
26
26
26
26
26
26
26
26
26
27
28
29
30
31
32
33
34
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | 81.44312.0009 | Колпак защитный | 2; | - | |
| 2 | Q218B1040TF2 | Стопор | 2; | - | |
| 3 | 81.92901.0066 | Гайка | 2; | - | |
| 4 | 81.44215.0016 | Шайба стопорная | 2; | - | |
| 5 | 06.32499.0016 | Подшипник SКF32310J2/А | 2; | - | |
| 5 | 06.32499.0034 | Подшипник FАG32310А | 2; | - | |
| 6 | Q30022 | Конический роликовый подшипник | 20; | - | |
| 7 | DZ9100410121 | Front wheel hub | 2; | - | |
| 8 | DZ9100410129 | Wheel fixture bolt | 20; | - | |
| 9 | 06.32499.0190 | Radial- row-steep roller bearing | 2; | - | |
| 10 | 06.56279.0340 | Packing ring for axle | 2; | - | |
| 11 | Q151B1645TF2 | Болт | 8; | - | |
| 12 | Q151B1640TF2 | Болт | 4; | - | |
| 13 | DZ9100410400 | Steering knuckle | 1; | - | |
| 13 | DZ9100410401 | Steering knuckle | 1; | - | |
| 14 | 06.56279.0343 | Packing ring for axle | 4; | - | |
| 15 | 81.93021.0270 | Top bush | 2; | - | |
| 16 | 81.44205.0055 | Pin | 2; | - | |
| 17 | 81.44208.0009 | Seal plate | 2; | - | |
| 17 | 190003963114 | Taper thread grease nipple | 4; | - | |
| 18 | Q43068 | Circlip for hole | 4; | - | |
| 19 | Q341B16 | Гайка № 1 | 2; | - | |
| 20 | DZ9100410405 | Fixed bolt | 2; | - | |
| 21 | DZ95009410003 | Knuckle arm | 1; | - | |
| 21 | DZ95009410004 | Knuckle arm | 1; | - | |
| 22 | Q151B2480TF2 | Hex bolt | 2; | - | |
| 23 | 81.46701.0290 | Steering trapezium arm | 1; | - | |
| 24 | Q151B2495TF2 | Hex bolt | 4; | - | |
| 25 | 81.46701.0289 | Steering trapezium arm | 1; | - | |
| 26 | 81.90713.0679 | Adjusting washer | ; | - | |
| 26 | DZ9100410419 | Adjusting washer | ; | - | |
| 26 | DZ9100410418 | Adjusting washer | ; | - | |
| 26 | DZ9100410417 | Adjusting washer | ; | - | |
| 26 | DZ9100410416 | Adjusting washer | ; | - | |
| 26 | DZ9100410415 | Adjusting washer | ; | - | |
| 26 | DZ9100410414 | Adjusting washer | ; | - | |
| 26 | DZ9100410413 | Adjusting washer | ; | - | |
| 26 | DZ9100410412 | Adjusting washer | ; | - | |
| 26 | 81.90713.0687 | Adjusting washer | ; | - | |
| 26 | 81.90713.0686 | Adjusting washer | ; | - | |
| 26 | 81.90713.0685 | Adjusting washer | ; | - | |
| 26 | 81.90713.0684 | Adjusting washer | ; | - | |
| 26 | 81.90713.0683 | Adjusting washer | ; | - | |
| 26 | 81.90713.0682 | Adjusting washer | ; | - | |
| 26 | 81.90713.0681 | Adjusting washer | ; | - | |
| 26 | 81.90713.0680 | Adjusting washer | ; | - | |
| 27 | DZ9003326025 | Push row-steep roller bearing | 2; | - | |
| 28 | Q151B16125TF2 | Hex bolt | 4; | - | |
| 29 | 06.33719.0097 | Quill roller | 2; | - | |
| 30 | DZ9100410406 | Packing ring | 2; | - | |
| 31 | DZ9100410426 | Front axle | 1; | - | |
| 32 | 81.52403.0021 | ABS ring | 2; | - | |
| 33 | DZ9100580215 | Втулка датчика | 2; | - | |
| 34 | DZ9100580214 | Датчик АВS | 2; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
