DC14251841122 AIR CONDITIONING CAB COMPONENTS
/ Shaanxi Shacman SX331853386 (X5000)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: DC14251841122 AIR CONDITIONING CAB COMPONENTS / Shaanxi Shacman SX331853386 (X5000)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
Поз. Артикул Название детали Кол-во Цена
1 Q1840820T1F31 Hexagon flange bolt 5; -
2 DZ14251841251 Air conditioning body assembly (x5000) 1; -
3 DZ14251841204 Air conditioning system warning sign (x3000) 1; -
4 81.97470.0073 Plastic fastening tape 1; -
5 DZ14251841221 Outdoor temperature sensor 1; -
6 Q2140625F60 Cross recessed pan head screws 1; -
7 DZ13241848912 Elastic clamp (29/with buckle) 2; -
8 DZ14251841009 Electric water valve bracket 1; -
9 Q221B4213F60 Cross recessed pan head tapping screws and plain washer assemblies 4; -
10 DZ14251845007 Pipe clamp 1; -
11 DZ14251841043 Evaporator compressor connecting pipe (i) 1; -
12 DZ13241821204 Кронштейн 1; -
13 Q401B06 Flat washer 5; -
14 Q40306F60 Washer 5; -
15 Q340B06F60 Hexagon nut 5; -
16 Q1840620T1F31 Hexagon flange bolt 1; -
17 Q1840616T1F31 Hexagon flange bolt 3; -
18 DZ13241821502 Fixed clip 1; -
19 Q230B0410F60 Cross recessed pan head screw and plain washer assembly 4; -
20 DZ13241841430 Filter housing assembly 1; -
21 81.61910.0011 Фильтр 1; -
22 06.13189.0099 Пластина-фиксатор SТ4,8-2-МАN183-В1 4; -
23 Q221B4816F60 Oval-head self-tapping screw 4; -
24 DZ14251841078 Condenser evaporator connecting pipe 1; -
25 DZ14251841116 Heating component 1; -
26 Q1840840T1F31 Hexagon flange bolt 2; -
27 DZ13241848911 Elastic clamp 2; -
28 DZ14251841107 Heater hose forming hose 1; -
29 DZ14251841108 Heater hose forming hose 1; -
30 DZ14251841110 Heater bracket 1; -
31 Q1840825T1F31 Hexagon flange bolt 3; -
32 DZ14251841021 Rubber sheath 1; -
33 DZ9100770423 Fixed clamp 5; -
34 DZ14251841012 Front drain pipe 1; -
35 DZ93189777161 Ordinary narrow tie 2; -
36 DZ14251841001 Drain pipe plugging cover 2; -
37 DZ14251841011 Drain pipe 1; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
