CAB LOCKING DEVICE (DZ14251440448)
/ Shaanxi Shacman SX331863366 (X3000)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
| Поз. | Артикул | Название детали | Кол-во | |
|---|---|---|---|---|
| 1 | DZ13241440148 | Right cab support assembly | 1; | |
| 2 | Q151B1480T1F3 | Hex screw | 2; | |
| 3 | DZ9L149778010 | Support | 2; | |
| 4 | DZ14251440090 | Polyamide tube | 2; | |
| 5 | Q150B1035T1F3 | Hex screw | 4; | |
| 6 | Q33210T2F3 | Hex nut | 8; | |
| 7 | DZ14251230320 | Right front support assembly | 1; | |
| 8 | DZ14251440356 | Bracket assembly | 1; | |
| 9 | DZ14251440060 | Air spring assembly | 2; | |
| 10 | DZ14251440346 | Regulating rod assembly | 2; | |
| 11 | DZ13241440036 | Height valve bracket | 2; | |
| 12 | Q33206 | Шайба стопорная | 4; | |
| 13 | DZ13241440080 | Right cab support bracket | 2; | |
| 14 | Q151C1265T1F3 | Hex screw | 4; | |
| 15 | 190003888457 | Гайка самоблокировочная | 4; | |
| 16 | DZ15221440037 | Height valve | 1; | |
| 17 | DZ14251440353 | Corrugated pipe | 2; | |
| 18 | DZ14251440056 | Support | 1; | |
| 19 | Q151B1490T1F3 | Hex bolt | 4; | |
| 20 | DZ93259820092 | Fuel injection pipe | 2; | |
| 21 | SZ144000755 | Polyamide tube | 1; | |
| 22 | 190003171356 | Лента крепления | 11; | |
| 24 | DZ14251440150 | Corrugated pipe | 1; | |
| 25 | DZ14251440517 | Fixed beam assembly | 1; | |
| 26 | DZ93259820091 | Fuel injection pipe | 1; | |
| 27 | DZ14251440350 | Ferrule-type compression | 2; | |
| 28 | Q351C12T15 | Nut | 2; | |
| 29 | DZ14251440057 | Support | 1; | |
| 30 | Q151B1485 | Hex screw | 4; | |
| 31 | DZ9100770423 | Fixed clamp | 4; | |
| 32 | Q150B0610 | Hex screw | 2; | |
| 33 | DZ13241440090 | Cab lock | 1; | |
| 34 | DZ15221440036 | Height valv | 1; | |
| 35 | DZ14251440337 | Polyamide tube | 1; | |
| 36 | DZ14251440343 | Support | 1; | |
| 37 | DZ13241440084 | Sleeve | 2; | |
| 38 | Q402B14 | Big gasket | 2; | |
| 39 | Q150B1070 | Hex screw | 2; | |
| 40 | DZ13241440088 | Adiabatic mantle | 1; | |
| 41 | Q401B10 | Washer | 2; | |
| 42 | Q150B1025T1F3 | Hex screw | 2; | |
| 43 | DZ13241440089 | Adiabatic mantle bracket | 1; | |
| 44 | Q151B14130T1F3 | Hex screw | 2; | |
| 45 | DZ14251230010 | Bracket assembly left | 1; | |
| 46 | DZ93189777031 | Fastening strap with fixing seat | 11; | |
| 47 | DZ13241440147 | Left cab support assembly | 1; | |
| 48 | DZ14251440355 | Height valve bracket | 1; | |
| 49 | DZ93259820093 | Fuel injection pipe | 1; | |
| 50 | DZ14251440055 | Support | 1; | |
| 51 | Q150B0616 | Болт | 1; | |
| 52 | 81.98181.6065 | Tee joint | 1; | |
| 53 | 190003888458 | Гайка | 10; | |
| 54 | Q401B16 | Plain washer | 2; | |
| 55 | DZ13241440083 | Sleeve | 2; |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
