  5. FRONT COVER

FRONT COVER
/ Shaanxi Shacman SX331863366 (X3000)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
3
4
4
5
5
5
5
5
5
5
6
7
7
7
7
8
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
10
11
11
11
11
11
12
12
12
12
12
12
13
14
15
16
17
17
18
19
19
20
20
21
21
22
23
24
24
25
25
26
27
28
28
29
29
30
30
31
32
33
33
33
33
34
34
35
36
37
38
39
40
41
42
42
Поз. Артикул Название детали Кол-во
1 DZ14251950001 Sq signboard 1;
2 DZ14251110066 Grille 1;
3 Q40205 Шайба 3;
4 Q340B05 Гайка 3;
5 DZ14251110022 Reed nut 10;
6 DZ14251110211 Front lid 1;
7 Q2214816 Cross recessed round head tapping screws 11;
8 DZ14251110064 Right spoiler corner plate outer plate 1;
9 Q2300616 Cross groove pan head screw and flat washer assembly 38;
10 DZ14251110263 Right air deflector innerboard 1;
11 Q40206 Шайба 8;
12 Q2140616 Болт 10;
13 DZ14251110065 Right spoiler corner plate mounting plate 1;
14 DZ14251110060 Left spoiler corner plate outer plate 1;
15 DZ14251110258 Left air deflector innerboard 1;
16 DZ14251110073 Front cover lock right mounting bracket 1;
17 Q340B10 Nut 4;
18 DZ14251110061 Right air deflector install board 1;
19 Q33006 Nut 2;
20 DZ14251110030 Buffer assy 2;
21 SZ111000711 Mask lock lock 2;
22 DZ14251110080 Lock assy 1;
23 DZ14251110075 Unlock hand shank 1;
24 Q40310 Шайба 4;
25 DZ14251110040 Air spring assy 2;
26 DZ14251110051 Limit block 4;
27 DZ14251110543 Front lid hinge assembly 1;
28 Q33008 Q32208 Nut 2;
29 Q40110 Шайба 8;
30 DZ14251110047 Left front handrail shield 4;
31 DZ14251110046 Left front handrail shield 1;
32 Q2300630 Cross groove pan head screw and flat washer assembly 1;
33 self tapping screw and Washer assembly self tapping screw and Washer assembly 4;
34 DZ14251110045 Self tapping screw 2;
35 DZ14251110044 Left front handrail ;
36 DZ14251110544 Right hinge assembly ;
37 DZ14251110054 Right front handrail shield ;
38 DZ14251110055 Right front handrail shield ;
39 DZ14251110053 Right front handrail ;
40 DZ13241110076 Cable sheath ;
41 DZ14251110071 Left front lid install trestle ;
42 Q150B1020 Болт ;
