DECORATIVE ASSEMBLY
/ Shaanxi Shacman SX5315GJB5V326C (X3000)
1
1
2
2
2
3
3
3
3
3
3
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
6
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
8
8
9
9
9
10
10
11
11
11
11
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | DZ14251110562 | Decorative panel right A column | 1; | - | |
| 1 | DZ14251110552 | Decorative panel right A column | 1; | - | |
| 2 | DZ14251970007 | Front decorative board on the right side | 1; | - | |
| 2 | DZ14251971012 | Decorative board on the right side/j | 1; | - | |
| 2 | DZ14251972012 | Decorative board on the right side/d | 1; | - | |
| 3 | DZ14251970045 | Sealing strip for side surrounding water tank | 2; | - | |
| 3 | DZ14251970047 | Sealing strip for side surrounding water tank | 2; | - | |
| 4 | DZ14251970016 | Decorative panels on the right side and rear | 1; | - | |
| 4 | DZ14251979994 | Decorative panels on the right side and rear | 1; | - | |
| 5 | Q2140620 | Винт | 10; | - | |
| 5 | Q40106 | Шайба 8х16х2-SТ-А3С | 10; | - | |
| 6 | DZ14251970009 | Plastic clip | 14; | - | |
| 7 | Q2714219 | Cross groove pan head self-tapping screw | 14; | - | |
| 7 | Q40205 | Шайба | 14; | - | |
| 8 | DZ14251110551 | Decorative panel left A column | 1; | - | |
| 8 | DZ14251110561 | Decorative panel left A column | 1; | - | |
| 9 | DZ14251970006 | Front decorative board on the left side | 1; | - | |
| 9 | DZ14251971011 | Decorative panel left front | 1; | - | |
| 9 | DZ14251972011 | Decorative panel left front | 1; | - | |
| 10 | DZ14251970015 | Decorative panel left rear | 1; | - | |
| 10 | DZ14251979998 | Decorative panel left rear | 1; | - | |
| 11 | Q2140616 | Болт | 2; | - | |
| 11 | Q40106 | Шайба 8х16х2-SТ-А3С | 2; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
