DECORATIVE ASSEMBLY
/ Shaanxi Shacman SX5315GJB5V326C (X3000)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: DECORATIVE ASSEMBLY / Shaanxi Shacman SX5315GJB5V326C (X3000)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
3
4
5
Поз. Артикул Название детали Кол-во Цена
1 DZ13241970001 Cross member assembly 1; -
1 DZ14251973022 Cross member assembly 1; -
1 DZ14251973021 Cross member assembly 1; -
1 DZ14251973020 Cross member assembly 1; -
1 DZ14251973016 Cross member assembly 1; -
1 DZ14251973012 Cross member assembly 1; -
1 DZ14251973011 Cross member assembly 1; -
1 DZ14251973010 Cross member assembly 1; -
1 DZ14251973009 Cross member assembly 1; -
1 DZ14251973008 Cross member assembly 1; -
1 DZ14251973007 Cross member assembly 1; -
1 DZ14251973006 Cross member assembly 1; -
1 DZ14251973000 Cross member assembly 1; -
1 SZ197000001 Cross member assembly 1; -
2 Q40110 Шайба 8; -
3 Q340B10 Nut 8; 80 ₽
4 DZ13241430536 Buffer 2; -
5 Q33410 Гайка ВМ10-8-МАN183-В1 2; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
