REAR SUSPENSION DC95319520816
/ Shaanxi Shacman SX5318GJBDT386TL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
29
29
29
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
| Поз. | Артикул | Название детали | Кол-во | Цена | |
|---|---|---|---|---|---|
| 1 | DZ95259520832 | Balance axis | 1; | - | |
| 2 | DZ95259520826 | Bracket lower connecting plate | 1; | - | |
| 3 | 190003900007 | Палец | 2; | - | |
| 4 | Q151B1465T1F3 | Hex head bolt-fine teeth | 16; | - | |
| 5 | Q40314 | Шайба пружинная | 16; | - | |
| 6 | 199014520227 | Stud bolts | 28; | - | |
| 7 | Q33016T13F2 | All metal hex flange face lock nut | 6; | - | |
| 8 | Q1801660TF2 | Hexagon flange face bearing toothed bolt | 4; | - | |
| 9 | Q1801645TF2 | Hexagon flange face bearing toothed bolt | 2; | - | |
| 10 | 190003871353 | Type 1 Hex Nut - Fine Tooth - A-- Nut | 28; | - | |
| 11 | DZ95259520825 | Bracket | 2; | - | |
| 12 | DZ91259520504 | Seal ring | 2; | - | |
| 13 | 199114520136 | Кольцо уплотнительное | 2; | - | |
| 14 | DZ91259520222 | Ring | 2; | - | |
| 15 | AZ9114520223 | Кольцо уплотнительное | 2; | - | |
| 16 | 199114520042 | Подшипник | 4; | - | |
| 17 | DZ95259520831 | Rear leaf spring assembly | 2; | - | |
| 18 | DZ91259527024 | Dtf hex flange nut | 16; | - | |
| 19 | DZ91259520038 | Balance shaft housing | 2; | - | |
| 20 | 190003962021 | Hex plug screw | 2; | - | |
| 21 | Q40308 | Шайба пружинная | 16; | 10 ₽ - 60 ₽ | |
| 22 | Q150B0822T1F3 | Hex head bolt | 16; | - | |
| 23 | DZ91259520211 | Shell cover | 1; | - | |
| 24 | DZ91259520212 | Shell cover | 1; | - | |
| 25 | Q151B1850TF2 | Hex bolt | 12; | - | |
| 26 | DZ91259520505 | O-ring seal | 2; | - | |
| 27 | DZ95259520845 | Stop washer | 2; | - | |
| 28 | DZ95259520845 | Stop washer | 2; | - | |
| 29 | 199014520192 | Positioning washer | 2; | - | |
| 29 | 199014520193 | Positioning washer | 2; | - | |
| 29 | 199014520194 | Positioning washer | 2; | - | |
| 29 | 199014520303 | Positioning washer | 2; | - | |
| 29 | 199014520306 | Positioning washer | 2; | - | |
| 29 | 199114520059 | Positioning washer | 2; | - | |
| 29 | AZ9100520008 | Positioning washer | 2; | - | |
| 30 | 199014520191 | Втулка | 2; | - | |
| 31 | DZ91259520301 | Hex head bolt | 2; | - | |
| 32 | Q72308T5F | Gasket | 2; | - | |
| 33 | 199000520006 | Направляющий палец | 2; | - | |
| 34 | 199114520146 | Rear spring riding bolt | 4; | - | |
| 35 | SZ952000770 | Riding bolt seat | 8; | - | |
| 36 | Q1811455TF3 | Hexagon flange face bearing toothed bolt - fine teeth | 2; | - | |
| 37 | Q150B1040 | Болт | 16; | - | |
| 38 | DZ95259521011 | Buffer block bracket | 4; | - | |
| 39 | 06.11251.2005 | Гайка М14х1,5-10-МАN183-В1 | 16; | - | |
| 40 | DZ9114521012 | Buffer block assembly | 4; | - | |
| 41 | Q40310 | Шайба | 4; | - | |
| 42 | Q340B10T2F3 | Type 1 hex nut | 8; | - | |
| 43 | DZ95259520435 | guide plate | 4; | - | |
| 44 | DZ95259520306 | Balance board | 4; | - | |
| 45 | DZ95259520302 | Balance board | 4; | - | |
| 46 | DZ95259520301 | Balance board | 4; | - |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
