VIEW MIRROR
/ Shaanxi Shacman SX5318GJBDT386TL

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
Схема/чертеж: VIEW MIRROR / Shaanxi Shacman SX5318GJBDT386TL
1
2
2
2
2
2
2
3
3
3
4
4
4
5
6
7
7
8
9
10
11
11
11
12
12
12
13
13
13
13
13
13
14
Поз. Артикул Название детали Кол-во Цена
1 Q2540620 Sunk crew 6; -
2 DZ13241770911 Left view mirror bracket assy 1; -
2 DZ13241770951 Left view mirror bracket assy/e-heat 1; -
2 DZ13241770971 Left view mirror bracket assy/e-heat/motor 1; -
2 DZ13241771911 Left view mirror bracket assy 1; -
2 DZ13241771951 Left view mirror bracket assy/e-heat 1; -
2 DZ13241771971 Left view mirror bracket assy/e-heat/motor 1; -
3 DZ13241770912 Main out view mirror assy 1; -
3 DZ13241770952 Main out view mirror assy/e-heat 1; -
3 DZ13241770972 Main out view mirror assy/e-heat 1; -
4 DZ13241770913 Wide angle view mirror assy 1; -
4 DZ13241770953 Wide angle view mirror assy/e-heat 1; -
4 DZ13241770973 Wide angle view mirror assy/e-heat 1; -
5 DZ13241770914 Lh dust cap 1; -
6 Q2540825F60 Sunk crew 4; -
7 DZ13241771940 Front view mirror assy 1; -
7 DZ13241770940 Front view mirror assy 1; -
8 Q40106F60 Washer 2; -
9 Q2140616F60 Pan head screw 2; -
10 DZ13241770930 Blind view mirror assy 1; -
11 DZ13241770912 Main out view mirror assy 1; -
11 DZ13241770952 Main out view mirror assy/e-heat 1; -
11 DZ13241770972 Main out view mirror assy/e-heat 1; -
12 DZ13241770953 Wide angle view mirror assy/e-heat 1; -
12 DZ13241770973 Wide angle view mirror assy/e-heat 1; -
12 DZ13241770913 Wide angle view mirror assy 1; -
13 DZ13241770921 Right view mirror bracket assy 1; -
13 DZ13241770961 Right view mirror bracket assy/e-heat 1; -
13 DZ13241770981 Right view mirror bracket assy/e-heat/motor 1; -
13 DZ13241771921 Right view mirror bracket assy 1; -
13 DZ13241771961 Right view mirror bracket assy/e-heat 1; -
13 DZ13241771981 Right view mirror bracket assy/e-heat/motor 1; -
14 DZ13241770924 Rh dust cap 1; -
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
