CAB LOCKING DEVICE
/ Shaanxi SX32566R384

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
1
1
2
3
3
4
5
5
6
6
6
7
8
9
10
10
11
11
11
12
12
13
14
15
16
16
16
16
16
16
16
17
18
18
18
18
18
18
18
18
18
19
19
20
20
21
21
23
24
25
26
27
28
28
28
28
29
30
31
31
31
31
31
32
33
33
Поз. Артикул Название детали Кол-во
1 DZ15221443021 Left cab support bracket 1;
1 DZ15221443051 Left cab support bracket 1;
1 DZ15221443171 Left cab support bracket 1;
1 DZ15221443121 Left cab support bracket 1;
1 DZ15221443123 Left cab support bracket 1;
2 DZ15221443041 Adiabatic mantle plate 3 1;
3 DZ15221443023 Adiabatic mantle plate 2 1;
3 DZ15221443082 Adiabatic mantle plate 2 1;
4 Q150B0825T1F3 Hex bolt 8;
5 DZ15221443081 Adiabatic mantle plate 1 1;
5 DZ15221443027 Adiabatic mantle plate 1 1;
6 DZ15221443048 Adiabatic mantle 1;
6 DZ15221443049 Adiabatic mantle 1;
6 DZ15221442037 Adiabatic mantle 1;
7 DZ15221443067 Silent block ;
8 Q151B14130 Hex screw 2;
9 Q40114 Шайба 2;
10 DZ15221443037 Left height valve plate 1;
10 DZ15221443079 Left height valve plate 1;
11 DZ15221440036 Height valv 1;
11 DZ15221440037 Height valve 1;
11 DZ13241440070 Height valve 2;
12 DZ15221443030 U-type plate 2;
12 DZ15221443035 U-type plate 2;
13 DZ13241440090 Cab lock 1;
14 Q151B14140 Hex bolt 2;
15 DZ15221443064 Silent block 2;
16 DZ15221443341 Left lockpin bracket 1;
16 DZ15221443083 Left lockpin bracket 1;
16 DZ15221443084 Right lockpin bracket 1;
16 DZ15221443342 Right lockpin bracket 1;
16 DZ15221443058 Right lockpin bracket 1;
16 DZ15221443057 Left lockpin bracket 1;
16 DZ15221443055 Left lockpin bracket 1;
17 Q150B0850 Hex bolt 4;
18 DZ15221443167 Cross member assembly 1;
18 DZ15221443095 Cross member assembly 1;
18 DZ15221443075 Cross member assembly 1;
18 DZ15221443230 Cross member assembly 1;
18 DZ15221443217 Cross member assembly 1;
18 DZ15221443360 Cross member assembly 1;
18 DZ15221443040 Cross member assembly 1;
18 DZ15221443345 Cross member assembly 1;
18 DZ15221443042 Cross member assembly 1;
19 Z15221443046 Adjusting rod 2;
19 DZ13241440046 Adjustable pole assembly 2;
20 DZ15221443020 Horizontal shock absorber 2;
20 DZ15221443120 Horizontal shock absorber 2;
21 DZ15221443080 Right height valve plate 1;
21 DZ15221443037 Left height valve plate 1;
23 DZ15221442006 Connecting bracket 2;
24 DZ13241440085 Cab lock 1;
25 Q151C1265TF2 Bolt – closely-pitched 4;
26 Q151B1470TF2 Hexscrew 2;
27 Q150B1070 Hex screw 2;
28 DZ13241440150 Spring strut 2;
28 DZ15221440400 Spring strut 2;
28 DZ15221440500 Spring strut 2;
28 DZ14251440020 Air spring 2;
29 Q151B1475 Hex bolt 6;
30 Q151B1450T1F3 Hex head bolt - fine teeth 1;
31 DZ15221443124 Right cab support bracket 1;
31 DZ15221443122 Right cab support bracket 1;
31 DZ15221443072 Right cab support bracket 1;
31 DZ15221443051 Left cab support bracket 1;
31 DZ15221443022 Right cab support bracket 1;
32 DZ15221443043 Height valve plate 2;
33 DZ15221443078 Height valve plate 2;
33 Q151B14150TF2 Hexscrew 4;
34 DZ15221440156 Bellows 1;
34 DZ14251440149 Bellows 1;
34 DZ15221440143 Bellows ;
34 DZ15221443292 Right bracket of adjusting rod assembly 1;
35 DZ15221443291 Left bracket of adjusting rod assembly 1;
