DOUBLE REDUCTION DRIVE AXLE WHEEL SIDE
/ Shaanxi SX32566R384

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
5
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
7
7
7
7
8
9
9
10
11
11
11
11
12
13
14
15
16
17
17
18
18
18
18
19
19
20
20
21
21
21
21
21
21
21
21
22
22
23
23
24
24
25
26
26
27
27
28
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
43
44
45
45
45
45
45
45
46
47
48
48
49
49
50
51
51
51
52
52
53
53
53
54
55
55
56
56
56
56
56
56
57
58
58
58
58
59
60
61
62
63
63
64
65
66
67
68
68
69
69
70
71
72
73
74
75
76
Поз. Артикул Название детали Кол-во
1 190003098026 Packing ring 4;
2 DZ9112346116 Square head tapered plug 4;
3 Q184A1018TF2 Hex flange surfaces bolt 20;
4 81.35114.0086 End cap 2;
5 06.29020.0216 Circlip for hole 2;
5 06.29020.0214 Circlip for hole 2;
6 81.90712.0877 Adjuster shim ;
6 81.90712.0876 Adjuster shim ;
6 81.90712.0875 Adjuster shim ;
6 81.90712.0874 Adjuster shim ;
6 81.90712.0873 Adjuster shim ;
6 81.90711.0606 Adjuster shim ;
6 81.90701.0808 Adjuster shim ;
6 81.90701.0755 Adjuster shim ;
6 81.90701.0754 Adjuster shim ;
6 81.90701.0753 Adjuster shim ;
7 81.90712.0878 Stop washer 4;
7 81.90711.0640 Stop washer 4;
8 06.29200.0117 Circlip for axle 2;
9 81.35113.0044 Central gear 2;
9 81.35113.0034 Central gear 2;
10 06.29160.0225 Circlip for axle 2;
11 DZ9112340776 Half axis 1;
11 DZ9112340775 Half axis 1;
11 81.35502.0129 Half axis 1;
11 81.35502.0128 Half axis 1;
12 190003884160 Гайка 20;
13 Q2541020 Болт 4;
14 81.50110.0144 Brake drum 2;
15 81.90010.0067 Hex bolt 10;
16 Q2541025 Bolt 4;
17 81.35114.0105 Hub redactor case 2;
17 81.35114.0110 Hub redactor case 2;
18 81.90711.0641 Stop washer 20;
18 81.90712.0880 Stop washer 20;
19 81.91020.0709 Planet gear axle 10;
19 81.91020.0698 Planet gear axle 10;
20 81.35112.0023 Plant gear 10;
20 81.35112.0029 Plant gear 10;
21 06.32569.0037 Quill roller bearing ;
21 06.32569.0036 Quill roller bearing ;
21 06.32569.0035 Quill roller bearing ;
21 06.32569.0034 Quill roller bearing ;
21 06.32569.0032 Quill roller bearing ;
21 06.32569.0031 Quill roller bearing ;
21 06.32569.0030 Quill roller bearing ;
21 06.32569.0029 Quill roller bearing ;
22 81.90712.0879 Space ring 10;
22 81.90711.0546 Space ring 10;
23 81.35114.0092 Planet carrier 2;
23 81.35114.0113 Planet carrier 2;
24 81.90620.0048 Hex nut 4;
25 81.90801.0224 Locking washer 2;
26 81.35111.0021 Inside gear ring 2;
26 81.35111.0017 Inside gear ring 2;
27 81.35114.0101 Gear ring bearer 2;
27 81.35114.0019 Gear ring bearer 2;
28 06.29020.0301 Circlip for hole 2;
28 06.29020.0240 Circlip for hole 2;
29 06.56341.4254 O-ring 2;
30 06.32499.0046 Row-steep roller bearing 2;
31 81.35701.0128 Wheel hub 2;
32 06.32499.0155 Row-steep roller bearing 2;
33 DZ9112340280 Space ring 2;
34 81.45501.0083 Wheel bolt 20;
35 81.35720.0005 Thrust gasket ring 20;
36 06.56289.0331 Grease packing 2;
37 06.56289.0371 Grease packing 2;
38 81.35730.0033 Oil baffle disc 2;
39 06.02828.4505 Болт 2;
40 81.90801.0225 Защитная пластина 2;
41 81.50212.0032 Фиксатор 4;
42 81.50211.0018 Фиксатор 4;
43 81.97610.0115 Пружина 4;
44 DZ9112340012 Кожух пыльника 1;
45 DZ9112340113 Brake camshaft 1;
45 DZ9112340114 Brake camshaft 1;
45 DZ9112340117 Brake camshaft 1;
45 DZ9112340118 Brake camshaft 1;
45 DZ9112340139 Brake camshaft 1;
45 DZ9112340140 Brake camshaft 1;
46 Q151B1445TF2 Hex bolt 20;
47 188000340023 O style packing ring 2;
48 188000340017 Bush 4;
49 DZ9112340143 Brake floor 1;
49 DZ9112340097 Brake floor 1;
50 188000440010 Washer 2;
51 Q340B08 Гайка 6;
52 DZ9112340145 Bracket 2;
52 DZ9112340146 Bracket 2;
53 Q151B1645 Болт 2;
53 Q151B16110 Болт 2;
53 Q151B1695 Hex bolt 4;
54 81.91020.0318 Stud 2;
55 Q40108 Шайба А8,4х16х1,6-200НV-МАN183-В4 4;
56 199000340057 Gap adjusting arm assembly 1;
56 199000340056 Gap adjusting arm assembly 1;
56 DZ9100340046 Brake adjuster 1;
56 DZ9100340045 Brake adjuster 1;
56 DZ9100340044 Brake adjuster 1;
56 DZ9100340043 Brake adjuster 1;
57 188000340022 Washer 2;
58 108000320046 Adjusting washer ;
58 108000320030 Adjusting washer ;
58 108000320029 Adjusting washer ;
58 108000320028 Adjusting washer ;
59 190003933116 Circlip for axle 2;
60 190003903661 Pin axle 2;
61 190003935015 Flat washer 2;
62 190003920328 Cotter pin 2;
63 06.38070.0102 Grease nozzle 4;
64 190003933300 Circlip for axle 2;
65 Q150B1012 Болт 12;
66 188000340037 Choke plug 4;
67 DZ9112340013 Кожух пыльника 2;
68 81.92201.0108 Заклепка ;
68 81.92201.0109 Заклепка ;
69 DZ9112340062 Тормозная накладка верхняя 4;
69 DZ9112340063 Тормозная накладка нижняя 4;
70 81.50211.0030 Фиксатор 4;
71 81.93021.0220 Bush 4;
72 DZ9112340061 Тормозная колодка 4;
73 81.50213.0013 Roller 4;
74 06.15113.2615 Шайба 4;
75 190003933072 Circlip for axle 4;
76 81.93021.0141 Втулка 4;
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
